Home | Heat pumps | NUOS SPLIT WH
Heat Pumps

NUOS SPLIT WH

NUOS domestic hot water heat pumps are able to set new efficiency standards by using heat from the air as a renewable source for high comfort and energy savings. NUOS SPLIT WH, versatile and easy to install, is the green evolution of traditional water heaters and is the result of Ariston's intensive research and development to improve energy efficiency and facilitate the use of the world-leading products.

Silent functioning, respectful to the quiet in your everyday life

Better exploitation of energy and renewable sources, enhanced performance

Longer durability and high performance thanks to the anti-corrosion Pro-tech technology

Automatic water heating cycle to prevent bacterial growth

request a quoterequest a quoteContact us
nuos_evo_split
nuos_evo_split
nuos evo split 1_1
nuos evo split 2_1

advantages and benefits

• Operating range in heat pump mode with air temperatures from -5 to 42°C

• Environmentally friendly gas R134A makes it possible to achieve water temperatures up to 62°C in heat pump mode

• Condenser is wrapped around the boiler (not immersed in water)

• Low noise emissions (outdoor unit)

• Titanium enameled steel boiler

• Integrated electrical heating elements

• Active anode (protech) + magnesium anode

• LCD Display

• Modes: green, auto, boost, boost 2, voyage and antilegionella modes withdrawal time setting

• Tank intended for indoor installation

request a quoterequest a quoteContact us
NUOS SPLIT WH
discover its features

  • ENERGY EFFICIENCY

    NUOS models are designed as an energy-efficient alternative to traditional electric storage water heaters.

    ENERGY EFFICIENCY
    ENERGY EFFICIENCY

  • ITALIAN DESIGN

    The elegant aesthetic is designed in collaboration with Italian designers, for an attention to detail that must be exhibited. The selection of materials is the basis of the beauty and essence of the NUOS models.

    ITALIAN DESIGN
    ITALIAN DESIGN

  • QUALITY

    100% GUARANTEED BY ARISTON: Every single component is developed in order to guarantee long-lasting performance and high efficiency, with the guarantee of the Ariston brand.


    100% CONTROLLED AND TESTED: Every single Ariston product is rigorously tested in terms of quality, efficiency and safety before being delivered, with superior results guaranteed by our commitment.


    100% BUILT TO LAST: Strong and super resistant materials, components and products developed to work in extreme conditions to provide high level results with maximum durability.

    QUALITY
    QUALITY

  • TOTALLY SAFE

    Designed with the most modern technology and built with selected materials, NUOS heat pumps are totally safe

    TOTALLY SAFE
    TOTALLY SAFE
NUOS SPLIT WH
discover its features

ENERGY EFFICIENCY

NUOS models are designed as an energy-efficient alternative to traditional electric storage water heaters.

ITALIAN DESIGN

The elegant aesthetic is designed in collaboration with Italian designers, for an attention to detail that must be exhibited. The selection of materials is the basis of the beauty and essence of the NUOS models.

QUALITY

100% GUARANTEED BY ARISTON: Every single component is developed in order to guarantee long-lasting performance and high efficiency, with the guarantee of the Ariston brand.


100% CONTROLLED AND TESTED: Every single Ariston product is rigorously tested in terms of quality, efficiency and safety before being delivered, with superior results guaranteed by our commitment.


100% BUILT TO LAST: Strong and super resistant materials, components and products developed to work in extreme conditions to provide high level results with maximum durability.

TOTALLY SAFE

Designed with the most modern technology and built with selected materials, NUOS heat pumps are totally safe

Technical data

Nuos Split 80

Nuos Split 110
TECHNICAL DATA

COP **

2,67

2,69

COP *

2,04

2,03

Warm-up time

3:11 h: min

4:28 h: min

Air min / max temperature

-5/42 ° C

-5/42 ° C

Max water temperature only heat pump / with R

62/75 ° C

62/75 ° C

Sound power (IU)

15 dB (A)

15 dB (A)

Sound power (UE)

57 dB (A)

57 dB (A)

Average absorbed electrical power

510 W

510 W

Nominal storage capacity

80 l

110 l

Maximum operating pressure

8 bar

8 bar

Voltage / Maximum absorbed power

220-240 / 1950 V / W

220-240 / 1950 V / W

Resistance power

1200 W

1200 W

Unladen mass (IU)

32 kg

38 kg

IP

IP24

IP24

Insulation thickness

41 mm

41 mm

Water connection diameter

1/2 M "

1/2 M "

Minimum storage room temperature

1 ° C

1 ° C

Heat loss (Pes)

20 W

24 W

V40 (quantity of water mixed at 40 ° C)

99 l

139 l
more information nuos_evo_split
