air source heat pump

NIMBUS COMPACT M NET R32

Floor standing air to water monobloc heat pump for heating, cooling and water heating

Thanks to the A+++ heat pump, performance is guaranteed all year round in both heating and cooling

Maximum silence in all operating modes.

With Ariston NET you have comfort at your fingertips. Remote control, consumption reports and online technical support, all in a free application for smartphones.

nimbus_compact_r32_1

advantages and benefits

  • Eco Refrigerant R32
  • COP up to 5.1
  • Low noise levels up to 53 dB(A)
  • Power range between 1.7 to 17.7kW
  • Modern and innovative design
  • Sensys NET HD system interface and external heat regulation sensor included as standard
  • Remote management with the Ariston NET app
  • Ultra-compact indoor unit (600x600mm) with integrated 180L cylinder featuring enlarged coil
  • 12L expansion vessel as standard
  • Magnetic filter as standard
  • Heating elements as standard
  • PV function
  • Install recommended:
    Anti-Freeze Kit - 3319687
    Drain Pan - 3024383


Talk to your local Ariston Representative on further specific accessories dependent on the type of installation. PSTI software support end date 16/08/2026.

NIMBUS COMPACT M NET R32
discover its features
  • OPTIMIZED PERFORMANCE

    The new upgraded Energy Manager 2.0 improves the integration of the system hardware and software to deliver optimal thermoregulation performance. This ensures higher energy savings and low-noise stable performance of the external units, even under challenging operating conditions.

  • ABSOLUTE EFFICIENCY

    High efficiency is guaranteed across the entire range both for heating and cooling operations. Already compliant with best-in-class A+++ energy performance and high COP of up to 5.1.

  • SMART CONNECTIVITY

    All products in the range can be remotely managed via Ariston Net App which enables an array of functionalities ranging from simplified product interaction to consumption optimization.

  • 360° CONTROL

    Users can create and control multiple-zone systems from anywhere using the new Sensys Net HD, which features an intuitive interface designed for a seamless pleasant user experience. Sensys Net HD also enables the integration and controlling of multiple renewable sources for maximum comfort and minimum environmental impact.

  • 100% MADE BY ARISTON

    All system components and software are internally developed by Ariston to ensure long-lasting performance, high-efficiency, and extended product life.

  • 100% AUTOMATICALLY CHECKED & TESTED

    Before leaving the plant, every single Ariston product undergoes a fully automated quality, safety and efficiency testing process with unlimited and instantaneous tracking capability.

NIMBUS COMPACT M NET R32
discover its features

OPTIMIZED PERFORMANCE

The new upgraded Energy Manager 2.0 improves the integration of the system hardware and software to deliver optimal thermoregulation performance. This ensures higher energy savings and low-noise stable performance of the external units, even under challenging operating conditions.

ABSOLUTE EFFICIENCY

High efficiency is guaranteed across the entire range both for heating and cooling operations. Already compliant with best-in-class A+++ energy performance and high COP of up to 5.1.

SMART CONNECTIVITY

All products in the range can be remotely managed via Ariston Net App which enables an array of functionalities ranging from simplified product interaction to consumption optimization.

360° CONTROL

Users can create and control multiple-zone systems from anywhere using the new Sensys Net HD, which features an intuitive interface designed for a seamless pleasant user experience. Sensys Net HD also enables the integration and controlling of multiple renewable sources for maximum comfort and minimum environmental impact.

100% MADE BY ARISTON

All system components and software are internally developed by Ariston to ensure long-lasting performance, high-efficiency, and extended product life.

100% AUTOMATICALLY CHECKED & TESTED

Before leaving the plant, every single Ariston product undergoes a fully automated quality, safety and efficiency testing process with unlimited and instantaneous tracking capability.

Technical data

NIMBUS COMPACT 35 M NET R32

NIMBUS COMPACT 50 M NET R32

NIMBUS COMPACT 80 M/M-T NET R32

NIMBUS COMPACT 120 M/M-T NET R32

NIMBUS COMPACT 150 M/M-T NET R32

PERFORMANCES IN HEATING

Capacity at -7°C / +35 °C (Min./Nom./Max.)

1.04 / 3.51 / 4.52 kW

1.04 / 5 / 5.20 kW

1.79 / 7.41 / 8.45 kW

2.73 / 9.51 / 11.47 kW

2.99 / 11 / 13.79 kW

COP nom -7°C / +35 °C

3.1

2.9

3.0

3.2

3.2

Capacity at +7°C / +35 °C (Min./Nom./Max.)

1.68 / 3.5 / 6.35 kW

1.68 / 5 / 7.57 kW

2.74 / 8 / 11.74 kW

4.23 / 12 / 14.37 kW

4.08 / 15 / 17.65 kW

COP nom at +7°C / +35 °C

5.1

5.0

4.8

4.9

4.7

Flow temperature (Min./Max.) - HHP only

-20 / 35 °C

-20 / 35 °C

-20 / 35 °C

-20 / 36 °C

-20 / 37 °C

Working temperature (air) Min./Max.

20 / 60 °C

20 / 60 °C

20 / 60 °C

20 / 60 °C

20 / 60 °C

PERFORMANCES IN COOLING
PERFORMACE IN DHW
ERP DATA
PRODUCT CODE
more information nimbus_compact_r32_1
